CKSR series
Maximum continuous DC primary current
40
90
35
30
25
20
15
10
5
0
CKSR 6-NP
80
70
60
50
40
30
20
10
0
CKSR 15-NP
0
20
40
60
80
100
120
0
20
40
60
80
100
120
T A (°C)
Figure 25: I P vs T A for CKSR 6-NP
90
T A (°C)
Figure 26: I P vs T A for CKSR 15-NP
160
80
70
60
50
40
30
20
10
0
CKSR 25-NP
140
120
100
80
60
40
20
0
CKSR 50-NP
0
20
40
60
80
100
120
0
20
40
60
80
100
120
T A (°C)
Figure 27: I P vs T A for CKSR 25-NP
T A (°C)
Figure 28: I P vs T A for CKSR 50-NP
The maximum continuous DC primary current plot shows the boundary of the area for which all the following conditions are
true:
- I P < I PM
- Junction temperature Tj < 125 °C
- Primary conductor temperature < 110 °C
- Resistor power dissipation < 0.5 x rated power
Frequency derating
1.25
1
0.75
0.5
0.25
0
AC Derating
10
100
1k
10k
100k
1M
f (Hz)
Figure 29: Maximum RMS AC primary current / maximum DC primary current vs frequency
Page 11/18
12October2012/version 8
LEM reserves the right to carry out modifications on its transducers, in order to improve them, without prior notice
www.lem.com
